LED Area Light, 170W/200W/220W/240W Selectable, 5000K, 36,000 Lumens, 120-277 VAC, Shorting Cap Included

LED Area Light - 170W/200W/220W/240W Selectable - Max 36,000lm - 5000K Daylight - Dark Bronze Finish - DLC 5.1 Premium - Commercial Outdoor Lighting

Product Description

The Lumens Depot LED Area Light delivers high-performance outdoor illumination with adjustable wattages (170W/200W/220W/240W) and maximum brightness of 36,000 lumens at 150lm/W efficiency. Engineered for versatility, this fixture supports Type III, IV, and V beam distributions and includes a shorting cap for quick photocell upgrades, making it ideal for street lighting, parking lots, and commercial outdoor environments.

Built from rugged die-cast aluminum with a dark bronze finish, this area light withstands harsh weather conditions with an IP66-rated sealed body, 10kV surge protection, and flow-through heat dissipation. Its low EPA design allows for wind-load optimization on poles, while the 1-10V dimmable driver ensures energy efficiency and lighting control.

Key Features

• Selectable Wattage: 170W / 200W / 220W / 240W

• High Output: Up to 36,000 Lumens (150lm/W)

• Color Temperature: 5000K Daylight

• Beam Distribution: Type III / IV / V (Optional)

• Shorting Cap Included (Photocell-Ready)

• Dimming: 0-10V & 1-10V Compatible

• Input Voltage: AC120-277V

• Construction: Die-Cast Aluminum with Dark Bronze Powder Coating

• Power Factor: ≥0.95

• Total Harmonic Distortion (THD): ≤20%

• CRI: Ra70

• Operating Temp: -40℃ to +45℃

• Integrated 10kV Surge Protection

• Heat Dissipation: Advanced Heatsink with Flow-Through Venting

• Low EPA for Wind-Load Optimization

• Wiring: 1.8ft Power Cord + 0.6m UL Power Cord (Dim wire not lead out)

• Certifications: DLC 5.1 Premium, UL/cUL Listed

• Warranty: 5-Year Limited Warranty

Recommended Applications

• Parking Lots

• Commercial Plazas

• Street & Roadway Lighting

• Industrial Facilities

• School Campuses

• Public Parks

• Perimeter & Security Lighting

Built for long-lasting durability and performance, the Lumens Depot LED Area Light offers unmatched flexibility, energy savings, and easy customization—making it the go-to choice for outdoor commercial and industrial lighting projects.
